Features:
- R-20U directional antenna provides enhanced signal pickup for UHF wireless microphone systems operating over 600 -800MHz frequency range and compatible with EU and US new telecom regulations.
- Light weight, durable construction, ABS cover for UV degradation, providing long life and stable performance under demanding operating conditions.
- Supplied in pairs, offering approximately 7dBi high directional effect which is ideal for extending the operating range and reliable of diversity UHF wireless systems.
- The power of the antennas is derived from the coaxial cable connected to RELACART R-14D antenna divider or HR-Series receivers.
- Designed for applications requiring increased distance between the transmitter and the receiver.
Specifications:
Frequency Range | 600-800MHz |
Gain | 7dBi |
Impedance | 50 |
Horizontal flap width | 80 ° |
Vertical flap width | 60 ° |
Polarization | Vertical |
VSWR | >2.0 :1 |
Connector | BNC |
Dimensions (mm) | 210(H) X 180(W) X 44(D) |
Weight | 300g |
