Product Description:
CS is a wide-range miniature condenser microphone with a cardioid polar pattern and an integral mute / low cut switch. It is designed for quality sound reinforcement, professional recording, elevision and other demanding sound pickup applications. The small-diameter, alternating adjustable-length gooseneck design permits highly flexible positioning while maintaining a smooth, well-contoured appearance. An included snap-on foam windscreen effectively reduces wind noise and “popping.”
The integral power module can be powered from any external 11V to 52V DC phantom power supply.
GS-380/450/530 Specifications
Element | Fixed-charge back plate permanently polarized condenser |
Polar Pattern | Cardioid |
Frequency Response | 35-18,000 Hz |
Low Frequency Roll-Off | 100Hz, 18 dB/octave |
Open Circuit Sensitivity | -32 dB(10.0 mV) re 1V at 1Pa |
Output Impedance | 200Ω |
Maximum Input Sound Level | 130 dB SPL, 1kHz at 1% T.H.D |
Dynamic Range(Typical) | 110 dB, 1kHz at max. SPL |
S/N Ratio | 68dB, 1kHz at 1Pa |
Switch | Flat, roll-off; mute/on |
Phantom Power Requirements | 11-52V DC, 4 mA typical |
Dimensions / Weight | GS-530 / AL-19F: 176g, 530mm |
GS-450 / AL-19T: 170g, 450mm | |
GS-380 / AL-19N: 166g, 380mm | |
Output Connector | Integral 3-pin XLRM-type |
Best Distance for Sound Pickup | 10cm~20cm |
GS-838/845/853 Specifications
Element | Fixed-charge back plate permanently polarized condenser |
Polar Pattern | Cardioid |
Frequency Response | 30-18,000 Hz |
Low Frequency Roll-Off | 100Hz, 18 dB/octave |
Open Circuit Sensitivity | -30 dB(10.0 mV) re 1V at 1Pa |
Output Impedance | 200Ω |
Maximum Input Sound Level | 130 dB SPL, 1kHz at 1% T.H.D |
Dynamic Range(Typical) | 110 dB, 1kHz at max. SPL |
S/N Ratio | >68dB, 1kHz at 1Pa |
Switch | Flat, roll-off; mute/on |
Phantom Power Requirements | 12-52V DC, 4 mA typical |
Dimensions / Weight | GS-853 : 190g, 530mm |
GS-845 : 170g, 450mm | |
GS-838 : 150g, 380mm | |
Output Connector | Integral 3-pin XLRM-type |
Best Distance for Sound Pickup | 20cm~60cm |
AL is a wide-range miniature condenser microphone with a cardioid polar pattern. It is designed for quality sound reinforcement, professional recording, elevision and other demanding sound pickup applications. The small diameter double gooseneck design permits highly flexible positioning while maintaining a smooth, well-contoured appearance. An included snap-on foam windscreen effectively reduces wind noise and “popping.”
The integral power module can
be powered from any external 11V to 52V DC phantom power supply.
AL-19F/19T/19N Specifications
Element | Fixed-charge back plate permanently polarized condenser |
Polar Pattern | Cardioid |
Frequency Response | 65-18,000 Hz |
Low Frequency Roll-Off | 100Hz, 18 dB/octave |
Open Circuit Sensitivity | -32 dB(10.0 mV) re 1V at 1Pa |
Output Impedance | 200Ω |
Maximum Input Sound Level | 127dB SPL, 1kHz at 1% T.H.D |
Dynamic Range(Typical) | 110 dB, 1kHz at max. SPL |
S/N Ratio | >68dB, 1kHz at 1Pa |
Switch | Flat, roll-off |
Phantom Power Requirements | 12-52V DC, 4 mA typical |
Dimensions / Weight | GS-530 / AL-19F: 176g, 530mm |
GS-450 / AL-19T: 170g, 450mm | |
GS-380 / AL-19N: 166g, 380mm | |
Output Connector | Integral 3-pin XLRM-type |
Best Distance for Sound Pickup | 10cm~20cm |
