Designed to be flown with AX2010A line array modules, the SW36XFA provides an elegant solution to delivering ‘bass in the sky’ from a flown cluster, with usable response down to 36 Hz. When positioned at the top of the array its integrated rigging hardware mates with the AX2010A and the curved grille profile also matches the AX2010, forming a neat and unobtrusive cluster.Offering impressive efficiency from a compact cabinet, the SW36XFA uses a combination of manifold and bandpass loading techniques to achieve an impressive 143 dB peak output. Its dual 18” low frequency drivers feature 4” Tetracoil dual voice coils, which have the equivalent performance to a single 6” voice coil.The SW36XFA features an integrated 4000 watt class D amplifier module that provides convenience and simplicity of connection for concert touring applications, or will benefit larger fixed installations such as dance clubs, sports halls, stadia, and large conference rooms. It will deliver high sound presure level at bass frequencies, with abundant headroom to deliver the fast transient response that brings live performances and electronic music to life. PROEL’s CORE DSP processing ensures that the SW36XFA is capable of perfect signal integrity, dynamic range in excess of 110 dB, and superior sonic performance.
System’s Acoustic Principle: Manifolded Band Pass
Frequency Response (±3dB): 36 Hz - 100Hz (Processed)
Maximum Peak SPL @ 1m: 143 dB
TRANSDUCERS
Type: Two 18” (460mm), 4” (100mm) VC
Cone: Water repellent cone and epoxy coated plates
Voice Coil Type: 100mm (4in) Tetracoil dual voice coil, equivalent to a single coil diameter larger than 152mm (>6in)
Suspension: Ultra linear suspension behavior
ELECTRICAL
Input Impedance: 20 kΩ balanced, 10 kΩ unbalanced
Input Sensitivity: +4dBu / 1.25 V
Signal Processing: CORE processing, 96kHz / 40bit floating point SHARK DSP, 24 bit AD/DA converters
Direct access Controls: 4 Presets (Standard/InfraSub/Cardioid/ User), Network Termination button, GND Link button
Remote Controls: PRONET control software
Network protocol: CANBUS
Amplifier Type: Class D with SMPS and PFC, Variable Switching Frequency
Output Power: 4000W
Mains Voltage Range (Vac): 90 - 260V 50/60Hz
IN / OUT Connectors: Neutrik XLR-M / XLR-F
IN / OUT Network Connectors: ETHERCON®(NE8FAV)
Mains Connector: PowerCon® (NAC3MPA)
Cooling: Variable speed DC fan
ENCLOSURE & CONSTRUCTION
Width: 74.5 cm
Height: 82.5 cm
Depth: 60 cm
Depth Including Wheels: 72.5 cm
Enclosure Material: 15mm, reinforced phenolic birch
Paint: High resistance, water based paint
Suspension system
Side Suspension: High Strength Steel with ¼ Fast Pin
Back Suspension: High Strength Steel with ¼ Fast Pin
Wheels: 4 heavy-load 100mm ø
Net Weight: 91.2 kg (201.1 lbs) without heavy duty wheels
