CS-200 System Overview
CS-200 conference system with easy installation and mounted, is an ideal choice for a variety of audio discussion conference applications, such as boardrooms, conference halls, houses of worship, universities and all type of public institutions. It has strong ability to provide multi-functional features, high security, ease of operation and good sound quality.
CS-100 discussion system overview:
CS-200M Central Controller
CS-200C chairman unit
CS-200D delegate unit
CS-200M Central Controller
- Advanced Conference Technology, conform to IEC60914 International Standard.
- Active 1/3/6 microphones in a time, chairman unit has the priority to override all delegate units.
- Auto microphone-off if no input sound in 40S.
- Control for up to 60 speaking units.
- Easy installation, simple operation.
- High quality voice resolutions, especially dmesigned for mini/medium type conferencing rooms.
- Stable and reliable connecting cable.
- Audio insertion facility to connect external audio processing devices or telephone couplers.
- Delicate and elegant design.
- Tabletop or mounted in a 19’’ rack.
- Two operational microphone modes: Discussion and AUTO.
Technical Specifications
|
Electricity | |
|
Electric Voltage for Power |
AC 110-220V 50/60 Hz |
|
Current consumption |
60W |
|
Audio Input |
RCA X 1 |
|
Audio Output |
RCA X 1 |
|
Microphone Input |
6.3mm connector |
|
In-ear monitor microphone output |
6.3mm earphone X1 |
|
Frequency response |
65Hz~15KHz |
|
S/N |
>90dB |
|
Installation |
Tabletop or mounted in a 19’’ rack |
|
Color |
Black |
|
Dimensionnï¼W X H X DDï¼ |
426(W)x88(H)x263(D) |
|
Weight (KG) |
4.5 |
CS-200C Chairman Unit
- Delicate and fashion design, easy to use.
- Advanced conferencing technology, compliant with ICE60914.
- Priority bottom to switch off the speaking unit.
- Built-in Hi-Fi loudspeaker to prevent acoustic feedback, the loudspeaker is muted when the microphone is on.
- With illuminated ring.
- Unidirectional condenser microphone for high quality sound pickup.
- Separate headphone with volume adjustment.
- Black or white for selection
CS-200D Delegate Unit
- Delicate and fashion design, easy to use.
- Advanced conferencing technology, compliant with ICE60914.
- Built-in Hi-Fi loudspeaker to prevent acoustic feedback, the loudspeaker is muted when the microphone is on.
- With illuminated ring.
- Unidirectional condenser microphone for high quality sound pickup.
- Separate headphone with volume adjustment.
- Black or white for selection.
Technical specifications:
|
Electricity | |
|
Frequency response |
60Hz-15KHz |
|
Current Consumption |
Maxxï¼120mA |
|
Output Power |
2 X 300mW |
|
Element |
Fixed-charge plate, permanently polarized condensers |
|
Earphone Output |
3.5mm earphone jack |
|
Earphone Carrier Impedance |
32Ohm |
|
Built-in Loudspeaker |
1W |
|
Machine | |
|
Installation |
Tabletop |
|
Dimension for base (WxHxD) |
w/o microphone 320(W)x57.5(H)x130(D) |
|
Color |
Black/silver |
|
Microphone Length(selectable) |
340mm/420mm(consented)x480mm |
|
Weight(KG) |
0.88 |
