OVERVIEW
The CS-101 is a compact and affordable audio conference system with automatic video tracking, yet meets all essential requirements for audio discussion applications. Easy installation and simple operation for variety of mini/medium type conferencing rooms.
FEATURES
- Advanced conferencing technology, compliant with ICE60914.
- Bright LCD display operation screen, with Chinese and English Language menu for choose, perfect function and easy operation.
- Active 1--4 microphones in a time, chairman unit has the priority to override all delegate units.
- Auto microphone-off if no input sound in 1--60S.
- Control for up to 60 speaking units.
- Control for up to 3 camera in series.
- Different Camera licence compliant, or specific licence requirement.
- Easy installation, simple operation.
- High quality voice resolutions, especially designed for mini/medium type conferencing rooms.
- Stable and reliable connecting cable.
- Audio insertion facility to connect external audio processing devices or telephone couplers.
- Pretty and fashion design.
- Tabletop or mounted in a 19’’ rack.
- Four operational microphone modes:
---- Sound control: Sound to open the microphone, when the maximum number of speakers is reach, subsequent microphone speaks.
SPECIFICATIONS
![](http://www.relacart.com/UploadFiles/2013924144756613.gif)
![](http://www.relacart.com/UploadFiles/2013924144826759.gif)
CS-101M Central Controller
Electricity | |
Electric Voltage for Power |
AC 100-240V 50/60 Hz |
Current consumption |
45W |
Audio Input |
RCA X 1 |
Audio Output |
RCA X 1 |
Frequency Response |
65Hz – 15KHz |
S/N.: |
>85dB |
Installation |
Tabletop or mounted in a 19’’ rack |
Color |
Black |
Dimensionnï¼W X H X DDï¼ |
410(W)x43(H)x206(D) |
Weight (KG) |
2.3KG |
![](http://www.relacart.com/UploadFiles/2013419171153762.gif)
CS-101C/D CHAIRMAN UNIT
- Delicate and fashion design, easy to use.
- Advanced conferencing technology, compliant with ICE60914.
- Priority bottom to switch off the speaking unit.
- With illuminated ring.
- Unidirectional condenser microphone for high quality sound pickup.
- Black or white for selection.
Frequency response |
65Hz-18KHz |
Current Consumption |
Maxxï¼85mA |
Output Power |
2 X 300mW |
Element |
Fixed-charge plate, permanently polarized condensers |
Machine | |
Installation |
Tabletop |
Dimension for base (WxHxD) |
Without soft tube microphone 105(W)x43(H)x150(D) |
Color |
Black/silver(consented) |
Microphone Length(selectable) |
340mm/420mm(consented)x480mm |
Weight(KG) |
0.78 |
